分类：中效空气过滤器
描述：
佰利乐0755-28660302
●框材：铝合金或镀锌板外框
●External frane：Aluminum alloy steel or frame
●滤料材质：新型复合无纺布
佰利乐●Filter material: new composite nonwoven fabric
●滤料颜色：F5(白色)45%（浅黄色）、F6(绿色)65%（桔红色）、F7(粉红色)85%（紫色）、F8(浅黄色)95%（深黄色）
●Liao color: The F5 (white) 45% (yellow), F6 (green) 65% (orange),F7 (pink) 85% (purple), F8 (yellow) 95% (deep yellow)
●密封条：醋酸乙酯
佰利乐●Gasket：EVA
佰利乐●使用最高温度、湿度：80℃、80%
●Use the highest temperature, humidity：80℃、80%
型号 model | 外形尺寸 Outside Dimensions (mm) | 额定风量 Rated air flow (m3/h) | 初阻力 Initial resistance(Pa) | 效率（级别） Efficiency (class) | 滤料颜色 Liao color | 袋数 pockets |
佰利乐 XN-10 | 495×295×500mm 佰利乐 20″×12″×20″ | 1000m3/h |
佰利乐 50Pa F5
55Pa F6 佰利乐 60Pa F7
65Pa F8
| 40-50% F5
佰利乐 60-70% F6 佰利乐 75-85% F7
85-95% F8 （比色法） 佰利乐 colorimetric | 白色F5 White 佰利乐 绿色F6 佰利乐 Green 粉红F7 pink 浅黄F8 佰利乐 yellow | 5 |
佰利乐 XN-18 | 495×495×500mm 20″×20″×20″ | 1800m3/h | 5 | |||
佰利乐 XN-13 | 595×295×500mm 24″×12″×20″ | 1300m3/h | 6 | |||
佰利乐 XN-22 | 595×495×500mm 24″×20″×20″ | 2200m3/h | 6 | |||
佰利乐 XN-26 | 佰利乐 595×595×500mm 佰利乐 24″×24″×20″ | 2600m3/h | 8 | |||
XN-12 | 佰利乐 495×295×600mm 20″×12″×24″ | 1200m3/h | 5 | |||
XN-22 | 佰利乐 495×495×600mm 佰利乐 20″×20″×24″ | 2200m3/h | 5 | |||
XN-16 | 595×295×600mm 24″×12″×24″ | 1600m3/h | 6 | |||
佰利乐 XN-27 | 佰利乐 595×495×600mm 24″×20″×24″ | 2700m3/h | 6 | |||
XN-32 | 595×595×600mm 24″×24″×24″ | 3200m3/h | 8 |
